Our AntiMigration Transfers are engineered specifically for sublimated and dyed polyester garments, where traditional prints risk color migration. Each transfer includes a specially formulated barrier layer that blocks dye bleed-through, keeping whites pure and colors vivid – even on dark or heavily dyed sportswear.
Produced with Pantone-matched screen printing inks, these transfers combine exceptional color accuracy with proven durability. The result is a smooth, flexible print that looks as bright as on cotton – but performs flawlessly on polyester jerseys, team uniforms, and sports numbers.
We count the anti-migration barrier as one additional color in production, making it a simple upgrade to our classic screen-print system without changing your workflow.
Technical Specifications
| Parameter | Description |
|---|---|
| Printing Method | Screen printing with additional highly effective blocking layer preventing color migration |
| Minimum Line Thickness | 0.6 mm (0.003 in) for best stability |
| Surface Finish | Matte or semi-gloss, with optional metallic effects (Gold, Silver) |
| Pantone Colors | All Pantone Coated colors available; inks are manually mixed for precise tone matching |
| Fabric Compatibility | Anti-Migration Layer for sublimated materials; mainly used for synthetic fabrics |
| Washing Resistance | Up to 60°C / 140°F wash resistance |
| Flexibility / Stretch | Moderate flexibility; retains color and shape after multiple washes |
| Opacity | Excellent coverage with strong, solid colors |
| Production Efficiency | Optimized for medium and high-volume orders |
| Carrier | Available on transparent film or paper |
Artwork / File Requirements
| Parameter | Description |
|---|---|
| File Types Accepted | AI, PDF, EPS, CDR, PSD, TIFF, PNG, JPG |
| Recommended Format | Vector or 300 dpi bitmap |
| Sheet Sizes | Printing area: 47 × 32 cm (18.5 × 12.6 in) 67 × 30 cm (26.4 × 11.8 in) 47 × 67 cm (18.5 × 26.4 in) |
| Arrangement | Multiple logos can be placed |
| Pricing | The price is calculated based on the number of colors, sheet format, and quantity |
| Cutting | Available on straight cutting lines |
Application Instructions
| Step | Setting / Description |
|---|---|
| Temperature | 150°C / 338°F |
| Time | 10-12 seconds |
| Pressure | 3-4 atm (medium) |
| Peel Type | Cold peel |
| Second Press | Recommended after removing film (3-5 sec) |
| Notes | Test before mass production for optimal settings per fabric |
Storage & Handling
| Parameter | Description |
|---|---|
| Storage Temperature | 15-25°C in a dry, flat area |
| Shelf Life | Up to 12 months from production |
| Handling | Avoid moisture and high heat before application |
Protect Your Print
Perfect for sportswear and synthetic fabrics where their coating could affect the color stability of the print
The Heat Press Settings. Easy and Clean.
150C
(302F)
Set up the heat press temperature
10-12 seconds
Set heat press timer
3-4 atm.
(Medium Pressure)
Set up the machine pressure
Cold Peel
Remove the film on cold
Please note that the recommended heat press settings may vary depending on your specific equipment and textiles. We suggest making a few test applications to determine the most optimal temperature and pressing time. If you encounter any difficulties, do not hesitate to contact our heat transfer experts for guidance.
